BGXH 30 BN BLOCK

    ₹ 2,043.00 ₹ 2,043.00 2043.0 INR

    ₹ 2,043.00

    This combination does not exist.

    Add to Cart Buy Now
    BGXH 30 BN
    Compact Non-Flange Type Block suitable to be used with BGR 30 Rail
    * High accuracy
    * Low Noise
    * Smooth Movement
    * High Load Rating
    * BGX 4-Groove Even Load Design
    * Made in Taiwan

    [STAF- Taiwan Block for Linear Guide]


    Description

    BGX 4-Groove Even Load Design

    The 4 rows of steel balls forms 45 degree contact with the grooves at 4 positions will balance the loads form all direction. This design that permits even load capacity in all directions no matter how the rails are mounted is widely adopted in all types of machines. Compared with the 2-groove Gothic design, the 4-groove construction is of better rigidity, accuracy and life. In particular, the auto-adjust capability allows quick accurate linear motions by eliminating the deviation of the mounting planes and the assembly errors.

    BGX Seal Design
    Incursion of foreign objects is normally the major reason of life shortening for rails because the accuracy of linear guides relies very much on circulation of the steel ball between the slide and the rail. Even the incursion of smallest objects can cause skipping and bumping of the slide and lead to permanent damage. Therefore, seal design is the key to linear slide quality. The seal design in BGX linear guides is divided into top and bottom seal systems aiming at the incursion passage of the foreign objects.

    BGX Oil Retaining in Circulation System
    BGX circulation system reserves a lot of space for retaining oil and is able to keeps a lot more oil. When linear slide moves, the oil inside spreads all over the prolongs the life
