MCS 6 - Length 1000mm

https://pbhmaxima.odoo.com/web/image/product.template/61458/image_1920?unique=34f5f24

[Maxima Hardened & Ground Shaft]

₹ 472.00 472.0 INR ₹ 472.00 Per Nos.

(Inc GST)
₹ 400.00 (+ GST 18% extra)

₹ 400.00

    This combination does not exist.

    ADD TO CART BUY NOW
    Maxima Shaft Dia : 6 mm
    * Case Hardened & Ground Chrome Plated
    * h7 Tolerance : -0 μm to -12 μm
    * Material : 45 High Quality Carbon Steel S45C
    * Hardness : HRC 55-60
    * Suitable for Linear Bearings, Pneumatic, Hydraulic applications

    Maxima Case Hardened & Ground Shaft Chrome Plated

    Customised End Machining

    • Tapping

    • Threading

    • Drilling

    • Step

    • Keyway

    • Snap ring groove

    • Chamfering

     We have in house facilities for machining of the shafts.

    for quote please email your drawing to sm@pbh.in

    Specifications :

    • Tolerance: h7

    • Case Hardened & Ground Chrome Plated

    • Material : 45 High Quality Carbon Steel S45C

    • Hardness : HRC 55-60

    • Depth of Hardness : 0.8 mm to 3 mm

    Suitable for :

    • Suitable Linear Bearings : LM 6 UU, LM 6 LUU, LMF 6 UU, LMF 6 LUU, LMK 6 UU, LMK 6 LUU, LMH 6 UU, LMH 6 LUU, SC 6 UU, SC 6 LUU

    • Applications: Linear Bearings, Pneumatic, Hydraulic applications


    Maxima Shaft Case Hardened & Ground Chrome Plated
