MCS 35 - Length 2000mm

https://pbhmaxima.odoo.com/web/image/product.template/61505/image_1920?unique=0a3509e

[Maxima Hardened & Ground Shaft]

₹ 4,484.00 4484.0 INR ₹ 4,484.00 Per Nos.

(Inc GST)
₹ 3,800.00 (+ GST 18% extra)

₹ 3,800.00

    This combination does not exist.

    ADD TO CART BUY NOW
    Maxima Shaft Dia : 35 mm
    * Case Hardened & Ground Chrome Plated
    * h7 Tolerance : -0 μm to -25 μm
    * Material : 45 High Quality Carbon Steel S45C
    * Hardness : HRC 55-60
    * Suitable for Linear Bearings, Pneumatic, Hydraulic applications

    Customised End Machining

    • Tapping

    • Threading

    • Drilling

    • Step

    • Keyway

    • Snap ring groove

    • Chamfering

     We have in house facilities for machining of the shafts.

    for quote please email your drawing to sm@pbh.in

    Specifications :

    • Tolerance: h7

    • Case Hardened & Ground Chrome Plated

    • Material : 45 High Quality Carbon Steel S45C

    • Hardness : HRC 55-60

    • Depth of Hardness : 0.8 mm to 3 mm

    Suitable for :

    • Suitable Linear Bearings : LM 35 UU,  LM 35 LUU, LMF 35 UU, LMF 35 LUU, LMK 35 UU, LMK 35 LUU, LMH 35 UU, LMH 35 LUU, SC 35 UU, SC 35 LUU

    • Applications: Linear Bearings, Pneumatic, Hydraulic applications

    Maxima Case Hardened & Ground Shaft Chrome Plated

    Tolerance Table h7

    Part NumberOuter Diameter (mm)Diameter Tolerance in micrometer h7
    MCS 66-0 μm to -12 μm
    MCS 88-0 μm to -12 μm
    MCS 1010-0 μm to -15 μm
    MCS 1212-0 μm to -18 μm
    MCS 1313-0 μm to -18 μm
    MCS 1414-0 μm to -18 μm
    MCS 1515-0 μm to -18 μm
    MCS 1616-0 μm to -18 μm
    MCS 1818-0 μm to -18 μm
    MCS 2020-0 μm to -21 μm
    MCS 2525-0 μm to -21 μm
    MCS 3030-0 μm to -21 μm
    MCS 3535-0 μm to -25 μm
    MCS 4040-0 μm to -25 μm
    MCS 5050-0 μm to -25 μm
    MCS 6060-0 μm to -30 μm
