Specification Sheet / Product Data
Side view and front view. Labels as in the PBH catalogue: dr shaft (bore) diameter, D outer diameter, L length, Df flange diameter, K flange width, t flange thickness, Dp fixing-hole pitch circle diameter, X fixing hole, Y counterbore diameter, Z counterbore depth. Dimensions in mm.
| Dimensions | |
|---|---|
| Part number | LMK 25LUU |
| Shaft diameter (dr) | 25 mm |
| Outer diameter (D) | 40 mm |
| Length (L) | 112 mm |
| Flange diameter (Df) | 62 mm |
| Flange width (K) | 50 mm |
| Flange thickness (t) | 8 mm |
| Pitch circle diameter (Dp) | 51 mm |
| Fixing hole (X), 4 holes | 5.5 mm |
| Counterbore diameter (Y) | 9 mm |
| Counterbore depth (Z) | 5.1 mm |
| Load & construction | |
|---|---|
| Basic dynamic load | 1,560 N |
| Basic static load | 3,140 N |
| Type | Square flange, long type, closed, double sealed (LMK…LUU) |
| Outer cylinder | Heat-treated steel |
| Ball retainer | Resin |
| Seals | Wiper seals on both sides |
| Fits shaft | Ø25 mm, e.g. MCS 25 |
Dimensions and basic load ratings are taken from the PBH catalogue.
Matching shaft
Use LMK 25LUU with the Maxima hardened and ground shaft MCS 25. Any length from 100 mm to 2000 mm.
MCS 25
Maxima Hardened & Ground Linear Shaft, Ø25 mm, h7
Other 25 mm bearing types
Standard, long, open, flanged and housed versions for a 25 mm shaft.
Features & construction
- High precision and rigidity: solid steel outer cylinder with an industrial-strength resin ball retainer.
- Flange mounting: bolts straight to the machine face with four screws, so no separate housing is needed.
- Easy to replace: standard LM dimensions and strict precision control, so it interchanges with other brands of the same size.
- Sealed on both sides: wiper seals keep dust out and hold the oil in.
The bearing has an outer cylinder, a ball retainer, balls and two end rings. The outer cylinder is heat treated for hardness and long travel life, and the end rings hold the retainer in place.
