Specification Sheet / Product Data
30 mmShaft diameter
72 mmLength (L)
78 mmWidth (W)
59.5 mmHeight (H)
1,574 NBasic dynamic load
2,740 NBasic static load
Maxima Linear Bearing SC 30UUHoused, resin retainer, double wiper seals
Front view and side view, labels as in the PBH catalogue. Dimensions in mm.
| Dimensions | |
|---|---|
| Part number | SC 30UU |
| Shaft diameter | Ø30 mm |
| Length (L) | 72 mm |
| Width (W) | 78 mm |
| Height (H) | 59.5 mm |
| G | 49 mm |
| A | 15 mm |
| h (±0.02) | 30 mm |
| D (±0.2) | 39 mm |
| J (±0.2) | 58 mm |
| K (±0.02) | 58 mm |
| E | 10 mm |
| Threaded holes (S1 x I), 4 holes | M8 x 18 |
| Mounting holes (S2), 4 holes | Ø7.0 |
| Load & construction | |
|---|---|
| Basic dynamic load | 1,574 N |
| Basic static load | 2,740 N |
| Type | Housed, closed, double sealed (SC…UU) |
| Bearing | Maxima linear bearing, resin retainer |
| Seals | Wiper seals on both sides |
| Fits shaft | Ø30 mm, e.g. MCS 30 |
Dimensions and basic load ratings are taken from the PBH catalogue.
Matching shaft
Use SC 30UU with the Maxima hardened and ground shaft MCS 30. Any length from 100 mm to 2000 mm.
MCS 30
Maxima Hardened & Ground Linear Shaft, Ø30 mm, h7
Other 30 mm bearing types
Standard, long, open, flanged and housed versions for a 30 mm shaft.
Features & construction
- High precision and rigidity: solid steel outer cylinder with an industrial-strength resin ball retainer.
- Housing included: the bearing is already fitted in its housing block, so it bolts straight down with four screws.
- Easy to replace: standard LM dimensions and strict precision control, so it interchanges with other brands of the same size.
- Sealed on both sides: wiper seals keep dust out and hold the oil in.
The bearing has an outer cylinder, a ball retainer, balls and two end rings. The outer cylinder is heat treated for hardness and long travel life, and the end rings hold the retainer in place.
